Switching power supply, DIN rail, 40 W, 24 V, 1.7 A

The new DIN rail switch-mode power supplies of the MDIN series from POS-Power stand out due to their high reliability and stability as well as their space-saving dimensions. This means that the switch-mode power lines can also be used without any problems in control cabinets with limited space. Installation is quick and uncomplicated thanks to the simple click system on standard DIN top-hat rails. In addition, the DIN rail power supplies are equipped with extensive protective devices (short circuit, overload, overvoltage, temperature) and display the DC-OK signal using the integrated LED.

Features:
Power: 40 W
Output voltage: 24 V DC (adjustable 28 - 35 V)
Output current: 0 - 1.7 A
low residual ripple: 400 mVpp
Efficiency: 82%
inrush current: max. 60 A
Universal input: 90 - 264 V AC
Type: constant voltage power supply
can be mounted directly onto the DIN rail (all common DIN rails such as TS-35/7.5 or 15)
closed design, touch-protected screw connections
Overload protection through current limitation, auto recovery
Protective devices against short circuit, overload, overvoltage, overheating
LED display and DC OK signal
low no-load power
operating temperature range: -20 ... +50 °C
Dimensions / Weight: 100 x 90 x 40 mm / 280 g
