Motorline MP300 RGB Flashing light For multiple applications
Motorline MP300
WARNING LAMPS - Choice of 3 Colours
Motorline MP300 RGB Flashing light For multiple applications
Universal LED flashing light with adjustable support for vertical or horizontal installation; Compatible with any electric gate control boards.
Power Supply from 12V to 230V AC and DC; Programmable for flash and steady light.
• 1 Motorline MP300 Warning Lamp
Characteristics
A single flashing light fits all projects, reducing the need for multiple models.
Designed for multiple applications, this flashing light is compatible with all types of control boards and offers simple and versatile installation, whether on top of barriers, pillars or even the MA4 antenna support.
Example of use - STOP/GO/WAIT
Easy connection to ALL control boards
Flashing light with integrated PCB for quick connection to Motorline RGB input.
It can also be connected to any control board with a 24–30Vdc output, allowing the selection of a single color.
• Full RGB control requires three dedicated outputs.
Compact and easy to install
Reduced dimensions and quick mounting, less installation time.
Technical Characteristics
|
LED power supply
|
24 to 30Vdc
|
|
RGB interface
|
Common cathode
Common input: 24 to 30Vdc Sink control via ground connection |
|
Current per channel
|
< 100 mA (R, G, B independent)
|
|
Maximum power
|
6 W (max.)
|
|
Available colors
|
RGB by cable input (red, green, blue)
|
|
Working temperature
|
-25°C to 55°C
|
|
Lighting angle
|
360°
|
|
Protection class
|
IP54
|
|
Box material
|
ABS / Polycarbonate
|
|
Dimensions
|
124x110x38 mm
|
